| Craft Lanka Model/Parameters | MCA3-18CRN1-Q CLE/CA-18CRN1 |
MCD-24CRN1-Q CLE/CD-24CRN1 |
MCD-36CRN1-Q CLE/CD-36CRN1 |
MCD-48CRN1-Q CLE/CD-48CRN1 |
MCD-60CRN1-Q CLE/CD-60CRN1 |
|
| Voltage (V) | 220-240 | 380/415 | ||||
| Phase/frequency (Hz) | 1/50 | 3/50 | ||||
| Cooling capacity (BTU) | 18000 | 24000 | 36000 | 48000 | 60000 | |
| Power input (W) | 2020 | 2600 | 4000 | 5150 | 6500 | |
| Operating current (A) | 9.5 | 12.5 | 8.2 | 8.7 | 9.5 | |
| E.E.R BTU/W.h | 2.3 | 2.71 | 2.78 | 2.73 | 2.71 | |
| Moisture removal (L/h) | 2.3 | 3.4 | 4.1 | 4.8 | 6 | |
| Filling Gas | R 410 A | R 410 A | R 410 A | R 410 A | R 410 A | |
| Air flow volume (H/M/L) (m2)/h | 810 / 650 / 530 | 1068 / 922 / 766 | 1800 / 1500 / 1300 | 1900 / 1600 / 1400 | 1900 / 1500 / 1300 | |
| Noise level (Indoor) dB (A | 41 / 41 / 37 | 48 / 43 / 38 | 53 / 50 / 47 | 54 / 52 / 50 | 55 / 53 / 51 | |
| Net dimension for unit - WxHxD (mm) | Indoor | 570 x 570 x 260 | 840 x 840 x 245 | 840 x 840 x 245 | 840 x 840 x 245 | 840 x 840 x 245 |
| Outdoor | 700 x 306 x 555 | 845 x 363 x 702 | 946 x 410 x 810 | 900 x 350 x 1170 | 900 x 350 x 1170 | |
| Packing dimension - Packages WxHxD (mm) | Indoor | 655 x 655 x 290 | 900 x 900 x 257 | 900 x 900 x 257 | 900 x 900 x 257 | 900 x 900 x 257 |
| Outdoor | 900 x 345 x 585 | 965 x 395 x 755 | 1120 x 435 x 1100 | 1032 x 443 x 1307 | 1032 x 443 x 1307 | |
| Piping Connection (Liquid-gas) Inch. | 1/4 - 1/2 | 3/8 - 5/8 | 3/8 - 3/4 | 3/8 - 3/4 | 3/8 - 3/4 | |
