| Model/Parameters | COU-24CR1/CUA-24CR1 CUA/COU-24CR1 |
COU-36CR1/CUA-36CR1 CUA/COU-36CR1 |
COU-48CR1/CUA-48CR1 CUA/COU-48CSR1 |
COU-60CR1/CUA-60CR1 CUA/COU-60CSR1 |
|
| Voltage (V) | 220-240 | 380-415 | |||
| Phase/frequency (Hz) | 1/50 | 3/50 | |||
| Cooling Capacity (BTU) | 24000 | 36000 | 48000 | 60000 | |
| Power Input (W) | 2400 | 3800 | 4700 | 5700 | |
| Operating current (A) | 10.6 | 7 | 8 | 10 | |
| E.E.R. BTU/W.h | 2.78 | 2.56 | 2.82 | 2.68 | |
| Moisture removal (L/h) | 3.6 | 3.6 | 4.8 | 6 | |
| Filling Gas | R 410 A | R 410 A | R 410 A | R 410 A | |
| Air flow volume (H/M/L) (m2/h) | 1300 | 1600 | 2300 | 2300 | |
| Noise level (Indoor) dB (A) | 39 - 48 | 52 | 57 | 507 | |
| Net dimensions for unit WxHxD(mm) | Indoor | 1245 x 247 x 680 | 1245 x 247 x 680 | 1670 x 247 x 680 | 1670 x 247 x 680 |
| Outdoor | 930 x 700 x 370 | 1070 x 995 x 400 | 1070 x 995 x 400 | 911 x 1330 x 400 | |
| Packing dimensions for packages WxHxD(mm) | Indoor | 1325 x 325 x 770 | 1325 x 325 x 770 | 1750 x 325 x 770 | 1750 x 325 x 770 |
| Outdoor | 990 x 770 x 410 | 1145 x 1120 x 475 | 1145 x 1120 x 475 | 964 x 1445 x 402 | |
| Piping Connection (Liquied-gas) Inch. | 3/8 - 3/8 | 3/8 - 3/4 | 3/8 - 3/4 | 3/8 - 3/4 | |
| Net weight of units Indoor/Outdoor (kg) | 35 / 48 | 37 / 72 | 47 / 88 | 47 / 87 | |
| Gross weight of units Indoor/Outdoor (kg) | 41 / 52 | 43 / 82 | 54 / 98 | 54 / 69 | |
